Control Lever
Model:
LTU-A1
LTU-B1
LTU-D1
HW-01

For main thrusters including (FPP/CPP)
For side thrusters
For azimuth thrusters
It's compatible with different types of propellers on modern ships, featuring a standard 4~20mA output signal and the ability to integrate telegraph functions. Each control handle has an optional motor, used to synchronize operations among all engines and propellers during control authority switching, thus achieving more precise and smooth control during navigation.
For rudder control


Standard
Lever UnitS   Single Lever
D   Dual Lever
Gear Sensation
10   Neutral Only; Lever Direction -60°—0—60°
11   Neutral Only; Lever Direction 0—60°
12   Five Forward, Neutral, Five Reverse; Feedback for Each Gear Position
13   Five Forward, Neutral, Three Reverse; Feedback for Each Gear Position
21   Five Forward, Parking Gear, Five Reverse; Feedback for Each Gear Position
00   Customized
Optional
E-Shaft
E   Achieve automatic synchronized control of lever commands across different control stations


Mechanical
Material6061 Aluminum Alloy, Aluminum Bronze, Stainless Steel
Surface TreatmentSandblasted followed by Hard Anodization (self-color or black), Oxidation, Mirror Polishing
Movement Range -60-60°
FrictionAdjustable
Dimensions 95×135×128.8 mm(120-130mm below)
Weight Approx. 2 kg(with motor approx. 2.5 kg)
InstallationPanel mount, E-Shaft Model lever comes with extra mounting plate
Electrical
Power Supply DC 18-28V (Powered by DC 24V)
Power Consumption 3W
Signal

4×DI (Active switch, backlight & telegraph control interface)

2×DO (Passive switch, forward & reverse signals)

1×AO (4-20mA)

Communication RS485 (Debugging Interface)
Dimming

Passive switch interface

Prev 1 2 Next
Standard
E-Shaft
(with mounting plate)
Appearance
Configuration
Specs
Cut-out
列表多图(1)
列表多图(1)(1)


Standard
Lever Unit
S   Singal lever
D   Dual Lever
Gear Sensation
10   Neutral Only; Lever Direction -60°—0—60°
11   Neutral Only; Lever Direction 0—60°
12   Five Forward, Neutral, Five Reverse; Feedback for Each Gear Position
13   Five Forward, Neutral, Three Reverse; Feedback for Each Gear Position
21   Five Forward, Parking Gear, Five Reverse; Feedback for Each Gear Position
00   Customized
Optional
E-Shaft
E   Achieve automatic synchronized control of lever commands across different control stations


Mechanical
Material6061 Aluminum Alloy, Aluminum Bronze, Stainless Steel
Surface TreatmentSandblasted followed by Hard Anodization (self-color or black), Oxidation, Mirror Polishing
Movement Range -60-60°
FrictionAdjustable
Dimensions 82×102×103.8 mm(83-106mm below)
Weight Approx. 1 kg(with motor approx. 1.5 kg)
Installation Panel mount, the motor on the electric shaft lever is detachable
Electrical
Power Supply DC 18-28V (Powered by DC 24V)
Power Consumption 3W
Signal

4×DI (Active switch, backlight & telegraph control interface)

2×DO (Passive switch, forward & reverse signals)

1×AO (4-20mA)

Communication RS485 (Debugging Interface)
Dimming

Passive switch interface


Prev 1 2 Next
Standard/E-Shaft
(detachable motor)
Appearance
Configuration
Specs
Cut-out


Standard
Axis Range10   Rotation Axis 360°, Thrust Axis -60°—0—60°
11   Rotation Axis 360°, Thrust Axis 0—60°
00   Customized
Optional
E-Shaft
E   Achieve automatic synchronized control of lever commands across different control stations


Mechanical
Material6061 Aluminum Alloy, Aluminum Bronze, Stainless Steel
Surface TreatmentSandblasted followed by Hard Anodization (self-color or black), Oxidation, Mirror Polishing
Movement Range360° rotation, ±60° tilt
FrictionAdjustable
Dimensions 96×96×120.8 mm(87-135.9mm below)
Weight Approx. 2 kg(with motor approx. 2.5 kg)
InstallationPanel mount, the motor on the electric shaft lever is detachable
Electrical
Power Supply DC 18-28V (Powered by DC 24V)
Power Consumption 3W
Signal

4×DI (Active switch, backlight & telegraph control interface)

2×DO (Passive switch, forward & reverse signals)

2×AO (4-20mA)

Communication RS485 (Debugging Interface)
Dimming

Passive switch interface


Prev 1 2 Next
Standard/E-Shaft
(detachable motor)
Appearance
Configuration
Specs
Cut-out


Standard
Movement10   Rotation spans 360°
00   Customized
Optional
E-Shaft
E   Achieve automatic synchronized control of helm wheel commands across different control stations


Mechanical
Material 6061 Aluminum Alloy, Aluminum Bronze, Stainless Steel
Surface Treatment Sandblasted followed by Hard Anodization (self-color or black)
Movement Range 360° rotation
Friction Adjustable
Dimensions 96×96×39 mm(39-129.5mm below)
Weight Approx. 0.85 kg(with motor approx. 1.1 kg)
Installation Panel mount, the motor on the electric shaft helm wheel is detachable
Electrical
Power Supply DC 18-28V (Powered by DC 24V)
Power Consumption 3W
Signal

2×DO (Passive switch, reserved for future use)

2×AO (4-20mA, default output for AO1)

Communication RS485 (Debugging Interface)


Prev 1 2 Next
Standard/E-Shaft
(detachable motor)
Appearance
Configuration
Specs
Cut-out
